OEM High performance Submersible Manufacture Analog Type Water Level Transmitters with Indicator

Product Categories
Xi'an Kacise Optronics Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

OEM High performance Submersible Manufacture Analog Type Water Level Transmitters with Indicator

Brand Name : Kacise

Model Number : GXPS400

Certification : certificate of explosion-proof, CE

Place of Origin : China (Mainland)

MOQ : 0-100

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal

Supply Ability : 1000 Pieces per Week

Delivery Time : 5-8 work day

Packaging Details : each unit has individual box and all boxes are packed in standard packages or customers requests available

Power supply : 24VDC, 11~30Vdc, or customized

Pressure interface : G1/4,input type

Operating Temperature : -40°C~85°C or -40 °C ~125 °C

Compensation temperature : -10°C~70°C

Accuracy : ±0.25%F.S, ±0.5%F.S, ±1.0%F.S

Stability : Typical value: 0.1%F.S Max.: 0.2% F.S/year

Pressure range : 0~1...500mH2O

Overload pressure : 1.5times Rated pressure

Secondary containment : 3 times rated pressure

Output signal : 4~20mA, 0~5Vdc, 1~5Vdc. 0~10Vdc

Contact Now

High accuracy Submersible Water Liquid Level Sensor Transmitter Price 0~200m

1.Product Description

OEM High performance Submersible Manufacture Analog Type Water Level Transmitters with Indicator

GXPS400 series level transmitter is a special structure and use of products, high precision, small size and good stability. Special strong cables for corrosive, abrasive, and chemical environment are offered according to filed environment. The products are approved with CE, intrinsically safe and explosion-proof certificates. Customized solutions for various fluids can be supplied.

2.Parameter

Spec. Numerical value
Accuracy ±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Stability Typical value: 0.1%F.S Max.: 0.2% F.S/year
Operating Temperature -40°C~85°C or -40 °C ~125 °C
Overload pressure 1.5times Rated pressure
Secondary containment 3 times rated pressure
Compensation temperature -10°C~70°C
Pressure range

0~1……500mH2O

9.8KPa…4900KPa

0.09bar…49bar

0.09atm…48atm

1.4psi… 711psi

2.8inchHg…1400inchHg
Response time 10ms
Electric strength 500Vac@1 second
Medium compatibility All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
Insulation 〉100MΩ@50V
Electrical Connections waterproof fixed cable + Two rectangle circle+ Sealing Rings+ seal gum+ Pure glue protection grade : IP68
Pressure interface G1/4,input type
Graduate Certificate Programs certificate of explosion-proof, CE
Electromagnetic compatibility electromagnetic radiation EN50081-1/-2, electromagnetic susceptibility: EN50082-2
Lightning protection air conduction resistance 8000V,case, cable conduction
Electrical properties 2 line 3 line 　
Output signal 4~20mA 0~5V 0~10V
Power supplies 10~30Vdc 80~30Vdc/ac 11~30Vdc/ac
Load resistance (U-10)/0.02(Ω) 〉100kΩ

3.Feature

  • Multiple pressure range and signal output
  • Non-polar 2 wire system current output
  • Can be used in lightning protection products
  • Diffused-Silicon oil filled core
  • All kinds of structure to satisfy different users
  • Easy to use with submersible measuring
  • Reinforcing rib for liquid cable available
  • Intrinsically safe explosion proof, Isolation explosion proof, CE
  • Four layers of waterproof protection

OEM High performance Submersible Manufacture Analog Type Water Level Transmitters with Indicator

4.Application Field

  • Fluid reservoir level measuring
  • Water-saving irrigation
  • Deep well level measuring
  • Hydrologic measurement for river, lake, sea
  • Sewage treatment
  • Circulating liquid consumption monitoring
  • Diversion project
  • Cloudy level measuring

5.Company Information

OEM High performance Submersible Manufacture Analog Type Water Level Transmitters with Indicator

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.

Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
