Multi Parameters Water Quality Testing Equipment 100mA Current RS485 Output

Name: Multi Parameters Water Quality Testing Equipment 100mA Current RS485 Output
Brand: Kacise
Price: 1500 USD

Multi Parameters Water Quality Testing Equipment 100mA Current RS485 Output Manufactures

Brand Name : Kacise

Model Number : KWS-800

Certification : certificate of explosion-proof, CE

Place of Origin : China (Mainland)

MOQ : 0-100

Price : USD1500-USD4000

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 100

Delivery Time : 5-8 working days

Packaging Details : each unit has individual box and all boxes are packed in standard packages or customers requests available

Operating temperature : 0~50℃

Output : RS485 Modbus

Full load power consumption : 0.8W (not rotating brush), 2W (rotating brush)

Cable length : Standard 10m, customizable 5m, 15m and 30m

IP Grade : IP68

Contact Now

Multi-parameters Water Quality Sensor for Turbidity, Condcutivity, PH,temperature, DO, Four in one testor

Introduction

The Kacise KWS-800 series of multi-parameter water quality sensors (seven optional parameters) are designed in an all-in-one configuration. Each sensor has a waterproof connector. Calibration data is stored in the sensor for field calibration and replacement. Up to 6 Kacise digital sensors can be connected at the same time, with optional fluori-dissolved oxygen, four-electrode conductivity, fiber turbidity, digital pH, digital ORP, chlorophyll and oil in water sensors. Equipped with an automatic cleaning device to eliminate air bubbles and prevent microbial growth, it can easily meet the needs of various water environment monitoring such as rivers, lakes, oceans and groundwater. Extremely reliable, it can run for months without maintenance in an unattended environment.

Feature

Digital sensor, RS485 output, support MODBUS
All calibration parameters are stored in the sensor, each with a waterproof connector for easy insertion and removal.
Equipped with automatic cleaning device, it can effectively remove the surface contamination of the sensor, prevent the growth of microorganisms, more accurate and lower maintenance.
Optional fluorimetry dissolved oxygen, four-electrode conductivity, fiber turbidity, digital pH, digital ORP, chlorophyll, water oil and ammonia nitrogen
Sensor for long-term online monitoring.
All-in-one structure design, can connect six probes at the same time and measure seven parameters.

Dimension

Multi Parameters Water Quality Testing Equipment 100mA Current RS485 Output

Technical Specifications

Multi-parameter sensor other information	Main body information	Support up to 6 sensor access, 1 central cleaning brush. Probe and brush can be disassembled, free combination.
	Size	Φ84mm*476mm
	Operating temperature	0~50℃
	Calibration data	The calibration data is stored in the probe, which can be disassembled for calibration.
	Output	RS485 Modbus
	Power supply	Complete machine:DC 12-24V,≥1A；probe:9-24V,≥1A
	Full load power consumption	0.8W (not rotating brush), 2W (rotating brush)
	Cable length	10 meters (default), customized
	Self-clean brush	Default cleaning interval is 30 minutes, adjustable cleaning interval settings available.
	Casing	POM, titanium alloy, anti-fouling copper
	Cable length	Standard 10m, customizable 5m, 15m and 30m
	Alarm	Internal power supply abnormal alarm, internal communication abnormal alarm, cleaning brush abnormal alarm.
	IP Grade	IP68
Fluorescent Dissolved Oxygen probe	Range	0-20mg/L or 0-200% saturation
	Accuracy	<1% or ±0.3mg/L
	Max. water depth	40m
Turbidity Probe (90°Scattered Light)	Range	0.1-1000 NTU
	Accuracy	<5% or 0.3NTU
	Max. water depth	40m
Four-electrode Conductivity Probe	Range	0~5000µS/cm	0-100mS/cm
	Salinity Range	0-2.5ppt or 0-80ppt
	Max. water depth	40m
Fluorescent Chlorophyll Probe	Range	0~500 ug/L
	Accuracy	<5% or 0.5 µg/L
	Max. water depth	40m
Digital PH probe (glass electrode method)	Range	0-14pH
	Accuracy	±0.02pH
	Max. water depth	20m
Oil-in-water Probe (UV Fluorescent)	Range	0-150ppm
	Linearity	R²>0.999
	Max. water depth	40m
ORP (Platinum electrode method)	Range	-1999~1999mV
	Accuracy	±20mV
	Max. water depth	20m
Fluorescence Blue-green Algae	Range	0-300,000cells/mL (0-2,000,000 cells/mL customized)
	Linearity	R²>0.999
	Max. water depth	40m
Built-in temperature probe	Range	0~50℃
	Resolution	0.1℃

Multi Parameters Water Quality Testing Equipment 100mA Current RS485 Output
