KUS650 Ultrasonic Level Sensor
1.Introduction
This sensor provides very short to long-range detection and ranging, in a compact, robust PVC housing,
designed to meet IP65.
2.Application
KUS650 series is used to indicate and monitor the changes of water pressure/water level value at the installation site, and upload the real-time data to the centralized management platform through the built-in wireless transmission module, which is convenient for users to manage intelligently and centralizedly. It is mainly used in the following industries:
• Fire water system • City water supply
• Sewage treatment • Long-distance heating
• Food industry • Chemical, energy
3.Features
. Designed for outdoor or indoor environments
. High sensitivity
. Free run operation can continually measure and output ranger information
. Sensor beam angle is 7 degrees.
4.Technical parameters
| Enter |
| Measured variable Liquid | level, material level |
| Maximum measuremen trange | 1.2-30m (can be customized according to demand) |
| Output |
| Comprehensive accuracy | ±0.15%FS/ 0.15℃ |
| Temperature compensation | -10℃～70℃ |
| Vibration effects | < ± 0.05%/g, 500Hz in all directions (according to IEC 68-2-64) |
| Rated conditions environmental conditions |
| Ambient temperature | -25～+85℃ |
| Storage temperature | -40～+85℃ |
| Protection class | IP68 , according to EN 60529 |
| Electromagnetic Compatibility | EN 61326/A2 Annex A (2001) |
| Display and control |
| Display | SFTN liquid crystal, white backlight, 5-digit display. |
| Limit | value Free setting |
| Parameter | setting Use 3 buttons |
| Unit | The unit is mm, and the default unit is m. |
| Weight | about 1.35kg |
| Materials of non-wetted parts |
| Joint | 1NPT, stainless steel, length 20mm (material and joint specifications can be customized according to customer requirements). |
| Electrical connection | Make waterproof connector, air vent cable entry according to EN 175301-803A standard |
| Measurement period | ≤ 100ms |
Selection reminder: For special requirements, please contact our company and indicate in the order.
Precautions:
1. If you need to calibrate the meter, please contact our company. Non-professionals are not allowed to calibrate the meter.
2. When calibrating the meter, please turn on the meter first, and calibrate it after 1 hour of constant temperature.
